PD ISO/TS 10303-16:2021 PDF

Industrial automation systems and integration. Product data representation and exchange - Description methods: SysML XMI to EXPRESS transformation

Первая страница стандарта PD ISO/TS 10303-16:2021

Открыть превью (PDF)

Название (английский):

PD ISO/TS 10303-16:2021

Industrial automation systems and integration. Product data representation and exchange - Description methods: SysML XMI to EXPRESS transformation

Статус документа:: Действующий
Формат:: Электронный (PDF)
Дата публикации:: 31 августа 2022 г.
ICS:: 25.040.40
SKU:: PD ISO/TS 10303-16:2021

Тип поставки:

Full version318 €Read online 24h10 €Read online 72h15 €

Язык документа:

ruen

Срок поставки:Мгновенная загрузка

Цена:318 €

Abstract

1 Scope This document specifies a mapping of SysML (ISO/IEC 19514:2017) constructs to EXPRESS (ISO 10303‑11:2004) elements for the purpose of representing SysML model represented in XMI (ISO/IEC 19509:2014) as EXPRESS (ISO 10303‑11:2004) schemas. The specified mapping is a one-way transformation from SysML information model represented in XMI into an EXPRESS schema.

NOTE Due to this limitation 10303-16 does not define the transformation of arbitrary SysML models to EXPRESS .

The following are within the scope of this document:

— the transformation of SysML metamodel constructs represented in XMI to EXPRESS elements for the purpose of representing SysML information models as EXPRESS schemas.

The following are outside the scope of this document:

— the transformation of SysML metamodel constructs into EXPRESS elements that are not used in the STEP Extended Architectu...
