PD ISO/TR 10300-32:2021 PDF

Calculation of load capacity of bevel gears - ISO rating system for bevel and hypoid gears. Sample calculation for scuffing load capacity

Первая страница стандарта PD ISO/TR 10300-32:2021

Открыть превью (PDF)

Название (английский):

PD ISO/TR 10300-32:2021

Calculation of load capacity of bevel gears - ISO rating system for bevel and hypoid gears. Sample calculation for scuffing load capacity

Статус документа:: Действующий
Формат:: Электронный (PDF)
Дата публикации:: 30 апреля 2021 г.
ICS:: 21.200
SKU:: PD ISO/TR 10300-32:2021

Тип поставки:

Full version407 €Read online 24h10 €Read online 72h15 €

Язык документа:

ruen

Срок поставки:Мгновенная загрузка

Цена:407 €

Abstract

What is ISO/TR 10300 ‑ 32 about? The ISO 10300 series discusses ‘Calculation of load capacity of bevel gears.’ ISO/TR 10300 ‑ 32 is the 32 nd part in the multi-series of documents that is applicable to the calculation of load capacity of bevel gears. ISO/TR 10300 ‑ 32 provides calculation examples for different bevel gear designs regarding the scuffing load capacity. The initial geometry data of the gear is necessary for these calculations. WARNING — The user is cautioned that when the formulae are used for large average mean spiral angles, (βm1 + βm2)/2 > 45°, for effective pressure angles, αe > 30° and/or for large face widths, b > 13 mmn, the calculated results of the ISO 10300 series should be confirmed by experience.

Who is ISO/TR 10300 ‑ 32 for? ISO/TR 10300 ‑ 32 on the calculation of load capacity of bevel gears is relevant to:

Manufacturers of bevel gears Product design engineers Mechanical engineers Industries/applications such as automotive, ma...
