Overview
ISO 23480:2013 - Tools for pressing - Sliding plates defines standardized dimensions, tolerances and designation rules for sliding plates used in press tools. The second edition (2013) specifies two plate types (Type A: one-face; Type B: two-face), includes illustrative figures and dimension tables, and references general tolerancing, fastener and drawing-edge standards. The standard supports consistent design, procurement and interchangeability of sliding plates in metal forming and stamping tooling.
Key topics and requirements
- Scope: Main dimensions and tolerances of sliding plates for press tools and the required designation format.
- Types covered:
- Type A - one-face sliding plates (with figure and table of dimensions)
- Type B - two-face sliding plates (with separate figure and table)
- Dimensions and tolerances: Dimension tables and figures define nominal sizes; general tolerances are governed by ISO 2768‑1 (medium, m) where applicable. Surface roughness values are indicated in the figures.
- Fasteners and sockets: Hexagon socket screw specifications reference ISO 4762 for compatibility with standard fasteners.
- Drawing edges: All edges of undefined shape shall comply with ISO 13715.
- Material: Selection is left to the manufacturer’s discretion. The document gives example materials (e.g., steel for Type A, bronze with embedded solid lubricant for Type B) but does not mandate specific alloys.
- Designation rules: Sliding plates are designated by the term “Sliding plate”, the standard reference (ISO 23480), the type (A or B), and the plate dimensions b × h × l in millimetres.
Examples:
Applications and users
ISO 23480 is intended for:
- Toolmakers and die designers specifying sliding plates in stamping, pressing and forming tools
- Production engineers and maintenance teams replacing or ordering standardized plates
- Purchasing departments and suppliers ensuring dimensional interchangeability
- Quality assurance professionals verifying compliance with tool component standards
Benefits include faster design cycles, simplified procurement, and improved interchangeability of press-tool components.
Related standards
- ISO 2768-1 - General tolerances (linear/angular)
- ISO 4762 - Hexagon socket head cap screws
- ISO 13715 - Technical drawings - Edges of undefined shape
