Overview
IEC 63522-27:2025 is an international standard developed by the International Electrotechnical Commission (IEC) that focuses on electrical relays, specifically the testing and measurement of electrical contact noise. This standard provides a uniform test method to evaluate the ability of various types of electrical relays to perform reliably under conditions such as transportation, storage, and operational use. The standard primarily addresses the measurement of spurious voltage, or “contact noise,” across closed relay contacts, which can affect relay performance and overall system reliability.
This document is applicable to a wide range of electrical relays including electromechanical relays, reed relays, reed switches, solid-state relays, time relays, and hybrid technologies combining these types. By defining test procedures and evaluation criteria, IEC 63522-27:2025 helps manufacturers and users ensure the quality and robustness of relays in critical applications.
Key Topics
-
Scope and Applicability
Defines testing for all kinds of electrical relays to measure their response to mechanical and operational stress.
-
Definition of Electrical Contact Noise
Contact noise refers to spurious voltage appearing across relay contacts when they are closed, potentially causing interference or false triggers in electrical circuits.
-
Test Procedure
- Energization of relay at rated coil voltage.
- Use of a test circuit with a standard 1 MΩ resistor and 24 V DC source.
- Measurement of contact noise using an oscilloscope or noise-level meter with a bandwidth from DC to 1 MHz.
- Optional shock and vibration tests depending on manufacturer specifications.
-
Test Conditions to Specify
Including energization values, shock/vibration parameters, test circuit design, waveform requirements, measuring equipment, noise limits, and any filters used during measurement.
-
Evaluation and Reporting
Ensures that contact noise remains within specified limits and provides detailed guidance on test reporting for reproducibility and compliance documentation.
Applications
IEC 63522-27:2025 is essential for industries and sectors where electrical relays are critical components, including:
-
Industrial Automation
Ensuring relay reliability in complex manufacturing and control systems to prevent false signals caused by contact noise.
-
Transportation Systems
Testing relays under vibration and shock conditions simulating transport environments to guarantee durability.
-
Energy and Power Management
Validation of relay performance in power distribution to avoid disturbances or unexpected interruptions.
-
Consumer Electronics and Appliances
Verifying relay contact integrity to ensure device safety and proper functioning.
-
Telecommunications
Emphasizing low-noise relay operation to prevent signal degradation or interference.
By standardizing the measurement of electrical contact noise, this document supports improved product development, quality assurance, and compliance across global markets.
Related Standards
IEC 63522-27:2025 is part of a comprehensive series on Electrical Relays – Tests and Measurements and should be used in conjunction with:
- IEC 63522-0: General and guidance for electrical relay testing and measurement, providing foundational terms and concepts.
- IEC 60050-444: International Electrotechnical Vocabulary-Elementary Relays, offering standardized terminology used in relay technology.
- Additional parts of IEC 63522 series (under preparation or published) covering other specific testing methodologies for relays.
For precise and up-to-date references, users should consult the IEC Products & Services Portal or the Electropedia online database.
