BS ISO 6358-2:2013 PDF

Pneumatic fluid power. Determination of flow-rate characteristics of components using compressible fluids - Alternative test methods

Первая страница стандарта BS ISO 6358-2:2013

Открыть превью (PDF)

Название (английский):

BS ISO 6358-2:2013

Pneumatic fluid power. Determination of flow-rate characteristics of components using compressible fluids - Alternative test methods

Статус документа:: Отменён
Формат:: Электронный (PDF)
Дата публикации:: 30 ноября 2013 г.
ICS:: 23.100.01
SKU:: BS ISO 6358-2:2013

Тип поставки:

Full version50 €Read online 24h10 €Read online 72h15 €

Язык документа:

ruen

Срок поставки:Мгновенная загрузка

Цена:50 €

Abstract

1 Scope This part of ISO 6358 specifies a discharge test and a charge test as alternative methods for testing pneumatic fluid power components that use compressible fluids, i.e. gases, and that have internal flow passages that can be either fixed or variable in size to determine their flow-rate characteristics. However, this part of ISO 6358 does not apply to components whose flow coefficient is unstable during use, i.e. components that exhibit remarkable hysteretic behaviour (because they can contain flexible parts that deform under the flow) or that have an internal feedback phenomenon (such as regulators), or components that have a cracking pressure such as non-return (check) valves and quick-exhaust valves. In addition, it does not apply to components that exchange energy with the fluid during flow-rate measurement, e.g. cylinders, accumulators, etc.

NOTE This part of ISO 6358 does not provide a method to determine if a component has hysteretic behaviour; ISO 6358‑1 does provide such a method.

Table 1 provides a summary of which parts of ISO 6358 can be applied to various components.

Table 1 — Application of ISO 6358 test methods to components
