BS ISO 230-10:2016 PDF

Test code for machine tools - Determination of the measuring performance of probing systems of numerically controlled machine tools

Первая страница стандарта BS ISO 230-10:2016

Открыть превью (PDF)

Название (английский):

BS ISO 230-10:2016

Test code for machine tools - Determination of the measuring performance of probing systems of numerically controlled machine tools

Статус документа:: Отменён
Формат:: Электронный (PDF)
Дата публикации:: 29 февраля 2016 г.
ICS:: 25.080.01
SKU:: BS ISO 230-10:2016

Тип поставки:

Full version50 €Read online 24h10 €Read online 72h15 €

Язык документа:

ruen

Срок поставки:Мгновенная загрузка

Цена:50 €

Abstract

1 Scope This part of ISO 230 specifies test procedures to evaluate the measuring performance of contacting probing systems (used in a discrete-point probing mode) integrated with a numerically controlled machine tool. It does not include other types of probing systems , such as those used in scanning mode or non-contacting probing systems . The evaluation of the performance of the machine tool, used as a coordinate measuring machine (CMM), is outside the scope of this part of ISO 230. Such performance evaluation involves traceability issues, is strongly influenced by machine tool geometric accuracy and can, in addition to the machine tool probing system tests specified in this part of ISO 230, be evaluated according to ISO 10360‑2 and ISO 10360‑5. Numerically controlled machine tools can apply contacting probing systems in machining process applications, such as

— identification that the correct workpiece has been loaded before machining,

— location and/or alignment of the workpiece,

— measurement of the workpiece after machining, but while still on the machine,

— measurement of the position and orientation of the machine tool rotary axes,
